Am Robotics ID-8mm Motor Coupling/Flange Hub with Threading Pack of 2

The AM Robotics ID-8mm Motor Coupling Hub/Flange is purpose-built to perfectly pair your 6mm motor shaft. Crafted from high-quality hardened Mild Steel (MS), this coupling offers superior sturdiness and durability compared to similarly sized aluminum alternatives. The use of MS material not only enhances its strength but also adds a reassuring heft. As a rigid, single-piece coupling, it effectively minimizes backlash, ensuring precise and reliable power transmission for your robotic applications. Am Robotics is a proud brand of Dynacraft Technologies, dedicated to designing, producing, and supplying a wide range of high-quality hubs, couplings, and Diy Chassis. We also welcome custom design suggestions, even for low-quantity orders, to meet your specific robotics needs.

Compatible Motors have a shaft diameter of 8mm,

Cytron IG42E Planetary Gear DC motor

Square Gear Box DC Motor

Compatible Wheels having a PCD of 35mm,

EasyMech 100mm Double Aluminium Omni Wheel (BUSH TYPE ROLLER)

EasyMech 100mm Double Aluminium Omni Wheel (BEARING TYPE ROLLER)

Features :

1. Quality assured branded couplings.

2. Equips high-quality MS.

3. Provides a good hold of the Motor Shaft.

4. Ensure the safe operation of your robot.

Inside Package:
1. Coupling/Flange x 2
2. Allen Key x 1
3.  M8 Grub Screws x 4
